Marantec Comfort 380 Superior Sectional Garage Door Operator



FEATURES
  • Blue Line technology energy efficient
  • High speed function / programmable
  • Soft Start, Soft Stop, Soft Run
  • Motor Head Rotatable 90°
  • Patented Marantec Safety Sensing
  • Multiple Features Independently Programmable
  • Secure – Push open security feature
  • Incorporated Diagnostics and counter
  • Battery Backup: Optional (100 – 1.3AH), (700 – 7AH)
  • Meets Stringent European Safety Requirements
SPECIFICATIONS
SUPPLY VOLTAGE 230V AC – 50Hz
CURRENT INPUT 1.1 A
CONTROL VOLTAGE 24V
CONSUMPTION During Operation – 0.25 KW; Standby – < 0.6 W
DRIVE 1100 N
SPEED 180 mm/sec. (standard door opening +/- 12 sec)
DUTY CYCLE S2 – 5 min
LIFT CAPACITY 220 kg
TEMPERATURE RANGE -20 – + 60° C
PROTECTION IP20 (Class II)
DIMENSIONS 360 x 135 x 335 mm
WEIGHT approx. 7.5 Kg
LIGHT 2 x 10-LED modules (160w equivalent)
RAILS BELT DRIVEN RAIL SYSTEM

S2 RAILS:  3m

                   3.3m

                   4m

(The Company reserves the right to amend product specifications and information without notice.)

Download Spec Sheet

Category:

Description

Superior Fast Garage Door Operator
