EURODRIVE MANUAL OVERIDE TUBULAR MOTOR ED120

 FEATURES
  • Manual Override – Push engage
  • Silent Operation
  • Mechanical Limits
  • Adaptors to suit tube Ø 101.6mm to 133mm
  • 53mm offset – Mounting bracket not required
  • Range of control options
  • Manufactured to High European Standards
SPECIFICATIONS
POWER SUPPLY 230V 50Hz
CURRENT  3.8 A
POWER 830 W
TORQUE 230 Nm
SPEED 12 RPM
LIFTING CAPACITY 350kg @ 100mm

280kg @ 127mm

265kg @ 133mm

Page 1 of 2



STANDARD ADAPTORS FOR TUBES

(If non-standard adaptors are required please contact Dortech with your requirements)

  • 101.6mm x 3.66mm (94mm)
  • 101.6mm x 1.63mm (97mm)
  • 127mm x 3.25mm (119mm)
  • 133mm x 5mm (123mm)

(The Company reserves the right to amend product specifications and information without notice.)

Download Spec Sheet
